Approvals

ASME A112.14.3-2000 Testing of Grease Interceptors, ASME A112.14.4-2001 Grease Removal Devices, CSA B481.0-2012 Testing of Grease Interceptors, CSA B481.1-2012 Testing and Rating of Grease Interceptors using Lard, CSA B481.5-2012 Testing and Rating of Grease Interceptors Equipped with a Grease Removal Device & PDI G 101. UL Approved (File No: E361705). Machinery Directive 2006/42/EC and EMC directive 2004/108/EC.

Flow Rates

Passive PDI =2GPM/7.571 L/m

Pro Active= 1 L/S

Application

10 to 12 Steam Combi Ovens only. If sink units are plumbed in then fit a PF or F. Do not exceed the rated flows.

Functions & Features

• Anti-Flood Pump - To maintain normal water level recalibration feature
• Water Connection - Water Solenoid WRAS approved (or similar approval)
• CIP Bar
• Pressure Switch & Air Sensor

Parts Supplied as Standard

• Vortex Flow Controller - Fitted as standard
• FlexiPlumb :- 34mm 90° bend (0635P02-34), 54mm 90° bend (0635P02-54)
• Blanking Cap (0635P10)
• Key(0509P86)
• ¾” Braided Hose For Hot Water (0214P15)
• Plumbing Pack see note

Default Program

(V5.4, V1.4)

Start 7.00 Am, Stop 02.30 Am. FOG roller pulsing 5 Min On 5 min off. An anti-Flood and Recalibration cycle, when water intake is activated FOG roller is inhibited. Mains lead per country.

Installation Kit

• Stainless Steel 304 hygiene and service access adjustable stand essential for installation.
• IP56 Socket. Best Practice Management and Do’s and Don'ts, both laminated to be displayed on site.
• Daily Maintenance Logbook (12 months)
• Sampling Point

Ratings

EU

• Voltage: 240 Volts
• Frequency: 50Hz
• Current: 0.49Amps

US

• Voltage: 120 Volts
• Frequency: 60Hz
• Current: 0.98Amps
